01
POSNBAT5
5.12 kWh
- Nominal voltage
- 51.2 V
- Capacity
- 100 Ah
- DC output
- 5.12 kW
- Installation
- Wall or floor
- 5.12 kWhWall-mounted
- 5.12 kWhRolling
- 10.24 kWhFloor-standing
- 16.08 kWhRolling
POSNBAT LOW-VOLTAGE SERIES
POSNBAT Low-Voltage LiFePO4 Battery Range
Three capacities. Four installation designs. Explore 5.12 kWh in wall-mounted or rolling form, alongside 10.24 and 16.08 kWh.
SERIES SPECIFICATIONS
Product specifications
Trackpad: swipe ← / → to switch models
Loading detailed 3D model…
POSNBAT16
Rolling- Cell technology
- LiFePO4 (LFP)
- Nominal energy
- 16.08 kWh
- Usable energy · 90% DoD
- 14.47 kWh
- Nominal capacity
- 314 Ah
- Nominal voltage
- 51.2 V
- Operating voltage
- 44.8 - 57.6 V
- Max. charge / discharge
- 200 A / 200 A
- Continuous DC output
- 10.24 kW
- Communication
- CAN / RS485 / dry contact
Installation & model information
- Configuration
- Rolling
- Model
- POSNBAT16
Confirm final enclosure dimensions, weight and mounting hardware with POSON before installation.
MODEL COMPARISON
Three models. One control and communication platform.
Review model-level energy, current and installation configuration before selecting the most suitable capacity for your market.
02
POSNBAT10
10.24 kWh
- Nominal voltage
- 51.2 V
- Capacity
- 200 Ah
- DC output
- 10.24 kW
- Installation
- Floor standing
03
POSNBAT16
16.08 kWh
- Nominal voltage
- 51.2 V
- Capacity
- 314 Ah
- DC output
- 10.24 kW
- Installation
- Floor standing
APPLICATION CONTEXT
Designed to be evaluated as part of a complete system.
Applications include residential solar self-consumption, backup for selected household loads and low-voltage hybrid or off-grid solar systems. Inverter compatibility, cable sizing, protection and local requirements must be confirmed for each project.
V2.1 inverter: CGI design concept · Engineering validation pending
COMMUNICATION & SYSTEM FIT
CAN / RS485, with compatibility confirmed per inverter.
Do not assume brand compatibility from voltage alone. Share the exact inverter model and protocol requirement before ordering.
- Nominal voltage
- 51.2 V
- Operating voltage
- 44.8 - 57.6 V
- Communication
- CAN / RS485 / dry contact
- Parallel expansion
- Up to 16 units*
DISTRIBUTOR DECISION PATH
Turn a product search into a structured buying conversation.
Use the model pages to compare specifications, download the series datasheet, and submit market, quantity and inverter requirements in one enquiry.
